Student desk.
Overall dimensions: 1000x866x750mm.
Tabletop with a triangular shape,
Particleboard thickness 16 mm. - color at the customer's choice. PVC edge 1 mm. - color gray.
The metal frame of the table has a functional geometric shape that fits under the corner tabletop.
The frame forms a triangular base that repeats the shape of the tabletop, but is slightly smaller for internal placement.
Legs: Three vertical legs are located at the three main corners of the structure. All legs have a rectangular cross-section, which gives the structure massiveness and stability.
Bottom connection:
A diagonal metal jumper in the shape of a "Y" passes below between the legs, which connects the supporting elements and provides structural rigidity, is connected using a steel sheet 3 mm thick, triangular in shape.
Top connection:
The upper part of the frame forms an open frame that exactly repeats the shape of the countertop for its fastening from above.
Metal frame:
Supports - rectangular profile pipe 50x20 mm, wall thickness 1.5 mm;
Crossbars - pipe 20x20 mm, wall thickness 1.5 mm;
Collapsible frame;
Painting - powder, polymer; Maximum load on the product: 120 kg.
Color: at the customer's choice.
Legs (footrests) - height adjustment up to 10 mm.
Maximum load on the product less: 120 kg. |
Materials | |
Chipboard thickness | 16 mm |
PVC plastic edge thickness | 1 mm |
Dimensions | |
Width | 1000 mm |
Depth | 866 mm |
Height | 750 mm |
Overall dimension | 1000х866х750 mm |
